Product Description
Features include:
- Damper control, broken pipe, fire mode and a payback counter
- LCD keypad HOA standard
- Side by side installation
- Heatsink out the back (flange option)
- Built-in EMC filter (optional for 480V)
- BACnet, Modbus-RTU, Metasys N2 communication protocol as standard
- Fan and pump drive up to 800hp
Specifications:
- Alternate Part Number 6730000700
- Horsepower 15 hp
- Housing/Enclosure IP20
- Input Phase 3 Phase
- Input Voltage 200-240V, 3 Phase
- Outdoor Rated No
- Output 3 Phase Output
- Series H100 Series
- Options Filtered Input - EMC Filter, Heatsink thru Back, Integrated EMC Filter, Keypad
- STO (Safe Torque Off) No
- Torque Load See Spec
- Drives - Type of Drive Fan and Pump/HVAC
- Warranty 2 Years
